SPECIFICATIONS

AI Functions: Smart Tracking

APP: Video link

Alarm Action: FTP Photo, Telefon Alarm, Email Photo, Local Alarm

Alarm Type: Local Alarm, FTP Photo, Email Zl Photo

App name: Other

Audio Output: Two Way Audio

Auto Tracking/Cruise: support

Auto Zoom: Support

Brand Name: TVPSii

Certification: CE, FCC, RoHS

Choice: Yes

Color: Black

Color Night Vision: Yes

Connectivity: IP/Network Wired

High Definition: 8.0 Megapixels

High-concerned chemical: None

IP Rating: IP67

IR Distance(m): 150m-200m

Installation: Wall Mounted

Internal Storage: Max.512GB

Lens (mm): 2MM

Lens Quantity: Single Lens

Megapixels: 8MP

Minimum Illumination(Lux): 0.01Lux-0.0001Lux

Model Number: TP-PTZ08B-54XS/90XS

Movement Range(Pan): 0°-360°

Movement Range(Tilt): Other

Operating Temperature: -60°-60°

Power Consumption(W): 20W-30W

Power Mode: Mains Electricity

Power Source: With Poe,Normal

Power Supply: With Poe

Power Supply(V): 12V

Protocol: Hikvision,Onvif,Dahua

Rechargeable Battery: NONE

Rechargeable Battery Capability: Other

Rotation: Horizontal: 360 degrees, Vertical: 90 degrees

Scene: Indoor and outdoor

Sensor: CMOS

Sensor Brand: Sony

Shell Material: Metal

Smart home platform: Other

Special Features: Waterproof / Weatherproof

Style: Dome Camera

Supported Mobile Systems: Android,iOS

Supported Operating Systems: No

TF Card: None

Video Compression Format: H.264,H.265

Viewing Angle : 360°

Warranty: 3 years

Whether or Not 50Vac or 75Vdc or Higher Power Supply: No

Zoom: 50x

Zoom type: Optical zoom

Is customized: No

Friendly reminder:

• All Camera is Double Light Mode, Support Infrared with Warm Led, can set full color and black white night vision.

• Compatible With Network Work Video Recorders Such as Dahua NVR; Hikvision NVR; XMeye NVR,TVPSII NVR and other Onvif protocol NVR.

• This Camera is POE PTZ Camera ,it can powered by 12V Power adapter, POE Switch, Poe injector or POE NVR.it can be controlled by phone(APP),PC(Web Browser, PC Software) and DVR NVR.

• Support automatic tracking, automatic cruise, and SD storage(so can choose buy camera with 128GB, 256GB SD Card).

• Support multiple cruise settings, fixed-point cruise, cruise between two points, cruise between multiple points and 360-degree cruise

• Automatic cruise and automatic zoom( Lens auto Zoom in and out) are the basic functions of the PTZ Camera. Many other brands of PTZ Camera do not support them, so Becarful!
