SPECIFICATIONS

Brand Name: NoEnName_Null

Compatible Camera Style: Camcorders

High-concerned chemical: None

Model Number: WN-IPN53-H46

Origin: Mainland China

Package: Yes

Product Parameters:

--Sensor:1/3" CMOS

--Lens:2.8MM-6MM

--Pixel:4MP

--SNR:≥50db(AGC OFF)

--WDR:DWDR: ＞80db

--Audio Input:1CH MIC Input

--Coding Format:H.265

--Main Stream:2560*1440,1-30 FPS/S 2304*1296,1920*1080,1280*720,1-30 FPS/S

--Sub stream:704*576,640*480,640*360,352*288,1-30 FPS/S

--Illumination:color 0.1Lux/F1.2, black/white 0.01Lux/F1.2

--Subtitle Overlay:Support channel name,Date&time,stream,resolution&5lines characters adding

--Video-coding Compression:128Kbps-3072bps continuous adjustable

--Data Record:Video, Picture

--Storage Method:Circular Recording, Alarm Recording

--Alarm Transfer:Browser, Management Software, IO Output

--Support Protocol:ONVIF

--PC Browser Mobile App:Support IE6.0 and above browser Support IOS,Android

--Temperature / Humidity:-20℃- +60℃ /0% - 90%

--Power supply:DC12V / POE

--Consumption:1.1W

--Network Interface:RJ45 Ethernet Port
